How One Can Benefit from ANSYS Complete Simulation Software?

When enrolling for ANSYS Online Training course from Multisoft Virtual Academy, participants are introduced to the advanced capabilities of Ansys Mechanical and how to utilize these capabilities to achieve desired outcome. In this training program, participants are introduced to the basics of ANSYS, Finite Element Modeling (FEM), and Finite Element Analysis (FEA).

There are 11 modules in the training program that covers topics, such as Introduction to FEA and Ansys, Basic Solid Modeling; Advanced Solid Modeling; Finite Element Modeling (FEM) I; Finite Element Modeling (FEM) II; Solution And Postprocessor; Static Structural Analysis; Advanced Structural Analysis (Dynamic And Nonlinear); Advanced Structural Analysis; Thermal Analysis and Generating The Report Of Analysis.

Let’s take a deeper look in to the key features of Ansys software.

Ansys Mechanical Training

Some of the key features of Ansys Mechanical are follows:

  • The software comes with powerful meshing and postprocessing capability, along with extensive contact and connection options built-in. Ansys Mechanical provides a dynamic environment that is based on a highly refined, intuitive, and customizable graphical user interface, which empowers users to receive quick and accurate answers so that the project keeps moving forward on time.
  • Includes many solver technologies that run in parallel and scale efficiently; where in the GPU technology can also be utilized for additional parallel computing power.
  • Modal, harmonic response, random vibration, and spectrum response (seismic or shock) can be solved with Mechanical.
  • Conduct acoustic simulations to better understand the vibroacoustic behavior of systems.  With or without structural pre-loading. Though, pre-loading adds authenticity and allows for the simulation of self-weighted, fastened assembly and even squealing breaks.
  • Along with the linear response, users can simulate the behavior of elastic materials as they undergo plastic or even hyperelastic deformation materials like metals and rubber. Viscoelastic response can also be simulated. Nonlinear simulation within Ansys Mechanical design also takes into account contact and large deflection of moving parts relative to each other, with or without friction. These capabilities are robust in static or time-domain transient simulations.
  • Robust steady-state and transient thermal capabilities are included with all levels of Mechanical design licenses. Heat transfer via conduction, convection, and radiation are supported. Thermal loading can also be readily transferred from Ansys’ CFD and electromagnetics solvers to Mechanical.
  • Extensive fatigue life and damage calculation capabilities are readily available in Mechanical. Combining fatigue life and fracture mechanic methods allows users to effectively predict the service life of their products and avoid costly warranty issues.
  • It intelligently predicts fluid-solid interactions accurately using pressure and/or heat transfer. As the fluid-structure interaction grows and the problem requires a more extensive analysis, Mechanical has automated, easy-to-use solutions for both one-way and two-way coupling to Ansys Fluent and Ansys CFX.

Benefits of Using Ansys Mechanical Capabilities:

  • Ansys Mechanical Pro can use multiple CPU cores when solving. As well as shared memory parallel (SMP) solvers, distributed solvers are available for a large range of analysis types, including linear dynamics. Using additional cores significantly increases solver performance. For larger models, the benefits of additional cores have been seen up to and beyond 1,000 compute cores.
  • Ansys Mechanical Pro enables nonlinear geometry solutions via a simple solver setting. Program-controlled settings take the guesswork out of solver controls. Geometric nonlinearities occur when a load applied to a structure no longer results in a linear response. This applies for large deflections and large strains. Running an analysis in which large strain or large deflection are present using a linear approach could yield very different results. Enabling large deflection means the solver will run a nonlinear solution, which will account for effects like stress stiffening and large strains. Comparisons between linear and nonlinear solutions are easy to generate using the “solution combination feature” as a comparison tool.
  • The post- process fatigue capability in Ansys Mechanical Pro is available to examine stress- and strain-based fatigue without the need to launch a separate tool. Being able to understand the immediate stresses and deformations a part undergoes is critical for structural analysis. Any part undergoing repeated loading may accumulate damage which will eventually result in part failure, even though the loading is not close to the limits of the material. Fatigue analysis lets you visualize damage during cycling of loads, and can help to predict where failure may occur so you can correct the problem and increase product durability.
  • Ansys Mechanical Pro includes a comprehensive range of contact capabilities so you can account for the interactions of multiple parts. Features range from bonded contact that treats joints between parts as if they are glued or welded together, to contact interfaces that allow parts to move apart and together with or without frictional effects.

Allows setting up complex shrink or interference that fits either from the simulation or from previously created overlapping geometry, thus enabling engineers to simulate the change in load paths when parts deform and confidently predict how assemblies will behave in the real world.

  • Enables easy import of loads from external sources. With Mechanical Pro it’s easy to analyze the interaction of different physics phenomena to better simulate real-world conditions. Simulations from other systems within the Ansys Workbench schematic can easily be linked together for even faster setup times for studying things like applying pressure calculated in CFD to structures.
  • Includes a full range of thermal capabilities for studying both steady-state and transient thermal analysis. Conduction through parts and across contacts can be set to accurately represent real conditions. Contacts can be adjusted to allow for imperfect conduction across parts where needed. Convection can be set up to represent various scenarios, and a library of predefined conditions is available. Allows performing steady-state and transient thermal analyses of products, including conduction, convection and radiation effects. Modeling phase-change and temperature-dependent materials ensures an accurate simulation.

Why choose Multisoft Virtual Academy for ANSYS Online Training course?

Multisoft Virtual Academy has been in training industry for more than 2 decades and backed by a team of global subject matter experts from around the world. When you enroll for ANSYS Online Training course from Multisoft, you get the opportunity to learn from experienced industry experts and gain experience and skills in ANSYS with hands-on experience from real-life projects and assignments. All the courses offered by Multisoft come with perks like lifetime access to e-learning material, recorded training session videos and after training support.

The courses are delivered in live instructor led, one-on-one and corporate training sessions, where after successful completion of the ANSYS Online Training course, aspirants receive a globally recognized training certificate to validate and showcase their learning and skills to employers across the world. What’s more? Multisoft after training support assists you to connect with potential employers and lucrative job opportunities in related areas, so that you can step up in the career ladder without delay.

Conclusion:

ANSYS is a very advanced software used to solve a wide variety of mechanical problems, including static/dynamic, structural analysis, fluid, acoustic, electromagnetic and heat transfer problems. Therefore, enrolling for ANSYS Online Training Course is highly recommended, as you need step-by-step guidance to understand the capabilities and navigate the software.
